| OA Size: | 4200 x 1620mm |
| Roller : | 3 x Keel rollers, 12 x Wobble rollers |
| Drawbar: | 50 x 70mm box tube |
| Chassis: | 50 x 50mm box tube |
| Cross bar: | 50 x 70mm box tube |
| Mudguard: | Stainless steel round guards |
| Axle: | Diameter 57mm Hollow Axle |
| Wheel: | 13 Inch Tyre with black Hot Dip Gal Rim |
| Spring: | 4Leaf Eye to Slipper Spring |
| Jockey wheel: | 6 inch Top Wind |
| Coupling: | AU STD Non-Braked |
| Winch: | 2600LBS Hand Winch |
| Light: | LED Light with 7Pin Plug (WATER PROOF) |
| Trailerweight: | 180KGS |
| max load: | 400kgs |
